Note:

• 1.2m² effective lightning area was tested by Qingdao Yilianke Information Technology Co., Ltd. Test conditions: the first arm of the lamp near the base was tilted forward by 19 degrees, the second lamp arm was raised, and the angle was 16.5 degrees with the horizontal, parallel to the tabletop, the luminous surface is 48cm from the height of the tabletop, and the lamp is adjusted to the maximum brightness.

• Covering the whole table, refers to the Mi Table Lamp Pro, capable of covering a full tabletop with a diameter of 125cm.

• Effective anti-glare, meet the requirements of GB/T9473-2017 "Reading and writing work table lamp performance requirements" shading requirements, tested by Weikai Testing Technology Co., Ltd., report number: CQC2018-1334.

• National standard A-level illumination, tested by Weikai Testing Technology Co., Ltd., report number: CQC2018-1334.

• Leaving Behind the previous gen lamp, the overall brightness is increased by 2 times +. The previous generation refers to the Mi LED Desk Lamp. Compared with the maximum brightness of the Mi LED Desk Lamp, the maximum brightness of the Mi Table Lamp Pro is more than 2 times.

• No visible ghosting, it is the result of Yeelight Lab test. Under the normal working condition of the whole lamp, the lamp light source surface is adjusted to the required position of the reading and writing work table lamp (usually 40cm from the desktop level), and the light source surface is parallel to the desktop. The standard obstacle level is placed directly below the desk lamp source, 10 cm away from the tabletop, and the number of shadows projected on the tabletop is observed. The test results have no visible ghosting. Any product of the strip light source has obvious ghosting in this environment.

• No stroboscopic light (also known as no flicker, undetectable brightness level), detected by Weikai Testing Technology Co., Ltd., report number: CQC2018-1334.

• Professional-Level reading and writing table lamp, refers to the Mi Table Lamp Pro that is in line with the national standard, the national standard CQC certification center certification, certificate number: CQC18010202694.

• Mi Table Lamp Pro supports two voice control modes, namely Xiao Ai and Siri.

• Stereo illumination design refers to the adjustable design of the Mi table lamp Pro’s three-stage shaft. The lamp head can be adjusted up and down by 45 degrees. The shaft near the lamp head can be adjusted upward by 30 degrees and downward by 40 degrees. The shaft near the base can be adjusted 15 degrees forwards and backwards, also can be adjusted each 30 degrees to the left and right. In this way, the whole lamp can be adjusted up and down, left and right, and front and rear. Without the movement of the lamp, the three rotating shafts can be flexibly matched to set the light in different spatial ranges and ensure effective illumination, so it is called stereo illumination design.

• For the description of the illuminance value of the table lamp in the video, the lamp head is parallel to the table top, the lamp head is 66cm away from the table top. The center point of the lamp head geometric center projected to the desktop is 578 lux, the lamp head is 48 cm from the table height. The test head geometric center is projected to the center of the table. The illuminance value is 1081 lux, the lamp head is 11 cm from the table top. The center point illumination value of the test head geometric center projected onto the table top is 14220 lux, the test is from Weikai Testing Technology Co., Ltd., report number: WTS2018-23970.

• Museum-level color-developing lighting, the data is based on GB/T 23863-2009 "Museum Lighting Design Specification" in places where display color, color fabrics and other multi-color exhibits have high requirements for color discrimination, general color rendering index (Ra) Should not be lower than 90.

• The color level of lighting in medical places is based on the color rendering index in the standard building form of GB50034-2013 “Architectural Lighting Design Standards” 5.2.6 Medical Building Lighting Requirements Lighting in the operating room and intensive care unit is indicated by Ra90 The other departments are Ra80, and the Mi table lamp Pro is referred to as Ra90, which is higher than the standard requirement value of this standard.

• The color rendering value (Ra) is 90, and the color temperature range of the Mijia table lamp Pro is 2500K-4800K. It is tested under the two limits of 2500K and 4800K, and Ra is not less than 90. Tested by Weikai Testing Technology Co., Ltd., report number: CQC2018-1334.

• German TUV Eye Comfort Certification, TUV Rheinland is an authoritative third-party organization for the certification of eye comfort, eye comfort certification for lamp safety, EMC, electrical characteristics, optical characteristics, life, stroboscopic, photo bio, noise and other indicators Test to ensure eye safety when using the product, no blue light hazard, certificate number: Q5042578.

• Imitation medical shadow less lamp technology, which means that the optical design of the Mi Table Lamp Pro is similar to the shadow less lamp principle of the medical operating table. Both of them adopt a circular light-emitting surface design, and the light source has a 360-degree lamp bead distribution, so that the center has no shadow.

• 100,000+ natural light adjustments, which is the result of Yeelight Lab test. The optical algorithm used by Mi Table Lamp Pro is Yeelight`s own optical algorithm. From the first generation of desk lamp (Mi LED Desk Lamp), it has been continuously improved. The algorithm has so far been optimized over 100,000 times.

• 25,000 hours of lamp life, measured by Foshan Water Testing Technology Service Co., Ltd., testing ambient temperature: 25 ° C, humidity: 65% RH, according to GB/T 5080.7 equipment reliability test, under constant failure rate assumption The failure test rate and the mean time between failure test procedures were tested to meet the 25,000 hour service life. Report number: WTF18F08122364N.

• 10,000 times of shaft down pressure test and 10,000 times of fatigue test, completed by Foshan Water Test Technology Service Co., Ltd., using shaft life test equipment, at the specified working angle (reserved 10 ° as the limit angle to prevent In the event of over-travel caused by the over-travel, each spindle was tested 10,000 times at 7 times/min to confirm that the appearance structure was normal and there was no bad hand feeling; after 5000 cycles, the torque attenuation of the shaft was ≤10%, experiment 10000 After the second rotation, the torque attenuation is ≤20%, and the lamp can be kept at any position in the normal working angle. The electrical performance of the function detection is normal and can be used normally. It is tested by Foshan Water Testing Technology Service Co., Ltd., report number: WTF18F08122365N.

• 54 shaft parts, the main body of the shaft is fully metal, and the total number of parts including the three shafts is 54, including 25 parts of the base shaft, 16 parts of the shaft on the lamp arm, and 13 parts of the shaft on the lamp head.

• 51-axis assembly process, from raw material to finished product, through 51 assembly processes such as die-casting, polishing, CNC machining, painting, assembly, etc., 54-axis spindle technicians carefully crafted, each product is inspected by inspection personnel. Strictly checked.
